EPC Smart Dimming Film-laminated Insulated Glass

EPC Smart Dimming Film-laminated Insulated Glass

Details
EPC smart dimming laminated insulated glass is an innovative photoelectric building material designed for modern high-end buildings and office spaces. It uses nano-level electrochromic core technology, allowing polarised crystals to align under an electric field, enabling second-level stepless adjustment of light transmittance, perfectly balancing spatial transparency and business privacy.
Category
EPC Intelligent Dimmable Film

Send Inquiry
Description
Technical Parameters

EPC Product Information



DiFei EPC smart dimming laminated insulated glass is an innovative photoelectric building material designed for modern high-end buildings and office spaces. It uses nano-level electrochromic core technology, allowing polarised crystals to align under an electric field, enabling second-level stepless adjustment of light transmittance, perfectly balancing spatial transparency and business privacy. In terms of performance and application, the product offers excellent heat insulation and UV resistance, effectively reducing building energy consumption. It features an EPC integrated trackless wiring design, hiding wires after installation in line with minimalist aesthetics. The double-layer ultra-clear laminated structure also provides explosion-proof and soundproof functions, and supports wall switches, remote control, and smartphone app multi-terminal control. After rigorous high-temperature, high-humidity, and weather resistance tests, the product remains colour-stable and performs consistently, fully meeting the standards for various high-end commercial office and partition projects.



Performance Metrics

Official Parameters & Specifications / Details

Industry Competitive Advantages

 Visible Light Transmittance (VLT)(VLT)(0-110V)

H:(Product Options): 2% - 65%

D: 1% - 55%

Ultra-Wide Dynamic Dimming Range

Dimming Contrast Ratio

Standard: 50x | Customizable: Up to 200x

Achieve Ultimate Light-to-Dark Contrast

(Haze)

ON (On-State): < 5%

OFF (Off-State): 100%

Ultra-clear in the bright state, highly shading in the dark state.

UV Blocking Rate

ON: 99% | OFF: 99.9%

Ultimate UV Protection

Response Time

OFF ➔ ON:≤ 2秒

ON ➔ OFF:≤ 9秒

Far faster than conventional electrochromic glass

Operating Temperature Range

-40℃ -- 90℃

Adaptable to extreme climates virtually anywhere worldwide

System Power Consumption

≤ 1 W/m²

Low Power Consumption, The Premier Choice for Green Buildings

Switching Cycle Life Test

> 1,000,000 次 (Testing Environment)

Long-lasting Durability Assurance

Maximum Manufacturing Size

Width up to 1.6m, unlimited length (Single sheet area > 5m²)

Meets the demand for large and extra-large curtain walls



Diverse application scenarios



  • High-end business offices: glass partitions in meeting rooms, executive offices, business reception and negotiation areas
  • High-end commercial and real estate: luxury villa sunrooms, dry and wet separation in hotel room bathrooms, glass display cases in showrooms and museums
  • Public and medical spaces: observation windows in high-end hospital wards, banks and VIP wealth management rooms



Installation and After-Sales Support



  • Customisation and Delivery: We provide tailored solutions based on the on-site measurements of your project to ensure a perfect fit.
  • After-Sales Expert Guidance: Detailed installation instructions are provided. Daily maintenance is easy, just wipe with a soft, slightly damp cloth and a neutral cleaner (take care to avoid water and moisture, and protect edge seals and electrical connections) to ensure long-lasting worry-free use.
